Inicio /Productos/Motores diesel/2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A

2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A

36
MOQ
$1,200
Precio
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Ataque: 4 tiempos
Cilindro: multicilindro
Estilo frío: Refrigerado por agua
comienzo: arranque manual
Dimensión (largo* ancho* alto): 1140x620x1070
peso: 420
Garantía: Un año después de la fecha de envío.
desplazamiento: 2251cc
Estándar de emisión: Otro
Potencia/velocidad nominal: 1500RPM
informe de prueba de maquinaria: Proporcionó
video-inspección-saliente: Proporcionó
componentes centrales: Motor
puntos clave de venta: Precio competitivo
potencia(w): 18.6 kW
Resaltar:

2105A-3A diesel engine water-cooled

,

diesel engine model 2105A-3A

,

water-cooled diesel engine 2105A-3A
Información básica
Lugar de origen: Jiangsu, China
Nombre de la marca: DURA
Pago y Envío Términos
Descripción de producto
Product Description

Usages

Diesel engine 2105A is an improved model of 2105 diesel engine. Its 12 hour rating is increased to 24ps or 26ps from original 20ps. Agricultural diesel engine units model 2105A-3A is a variant of 2105A diesel engine. It is  applied as drive power for irrigation and drainage, processing machines of products from farm and sideline, etc.

Features

* Advanced technique after experiences of production through a long history * Compact, rigid and reliable, easy to operate and maintain * Steady performance, high power reserve * With separate bearing assembly and drive pulley * With sliding-type mounting frame.
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 0
Model
2105A-3A
Type
Vertical,4-Stroke,Swirl
combustion chamber
Cylinder number
2
Bore(mm)
105
Stroke(mm)
130
Compression Ratio
20:1
Rated Rotation(r/min.)
1500
Rated Output(kw)
17.65
Over-load Output(kw)
19.41
Specific Fuel Consumption(g/kw.h)
≤251.6
Specific Oil Consumption(g/kw.h)
≤2.04
Lubricating Method
Pressure combined with
splashing and oiling
Cooling System
Open-type
water-cooling
Method of Starting
Manual starting
Rotating Direction of Crankshaft
(Facing Flywheel)
Counter-clockwise
Net weight(kg)
420
Gross weight(kg)
470
Dimensions(L x W x H)(mm)
1140 x 620 x 1070
Related Products
Packing&Shipping
 Packing: plywood case One 20’ GP container fits to load 36pcs of 2105A series diesel engines.
After Sales Service
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 2

Pre-Sales Service

* Inquiry and consulting support. * Sample testing support. * View our Factory.
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 4

After-Sales Service

* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Company Introduction
WUXI TRIPOD MACHINERY, being one of your reliable choices, is providing you success and blazing a new way leading to more benefits for your purchase. Our Aim We are striving to be the eyes of purchasers, brain aide of decision-making and hand of inspection on finished products. Our Motto The efforts is the base of on-going business, the credit creates essence of trade expansion.
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 6
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 8
2105A-3A Diesel Engine Water-Cooled Style Model 2105A-3A 10
